ABYSS® 24V 60Ah Trolling Motor Lithium Battery Kit

ABYSS® 24V 60Ah Trolling Motor Lithium Battery Kit

TMK-24V60-BT

  • In stock, ready to ship
  • Inventory on the way
Regular price$1,699.99
/
Shipping calculated at checkout.
ABYSS® 24V 60Ah Trolling Motor Lithium Battery Kit

Safe
RoHS
Compliant

ABYSS® 24V 60Ah Trolling Motor Lithium Battery Kit

5-year free replacement warranty

ABYSS® 24V 60Ah Trolling Motor Lithium Battery Kit

30 day risk
free money back guarantee

ABYSS® 24V 60Ah Trolling Motor Lithium Battery Kit

UN/DOT
38.3 Hazmat
Approved

Tired of having to constantly recharge your trolling motor battery? What about that lingering fear of your battery dying in the middle of your fishing trip?

Swap your unreliable trolling batteries for a powerful ABYSS® 24V 60AH Lithium Trolling Motor Battery. This single group 24 battery is compact, lightweight, and frees up storage space by replacing two 12 Volt Lead-Acid or AGM group 31 batteries in series. This Trolling motor battery kit includes our On-Board 24V  High Precision Lithium Charger so you can get the quickest, most intelligent, and efficient charge for your battery.

Whether you’re trolling in calm weather or fighting the wind, this battery will back you up even with load-heavy consumption. Ideal for deep cycle applications in diverse marine environments, seasons, and temperatures, The Abyss Battery® 24V 60Ah Lithium Trolling Motor Battery gives you a long and steady draw to last even for multi-day fishing trips. Just set it, charge it, and off you go. Tight lines!



    24V 60Ah Battery Datasheet

    Technical Specifications Details
    Nominal Voltage 24V
    Nominal Capacity 60Ah
    Parallel Connection Maximum 6 units
    Series Connection Maximum 2 units
    Bluetooth Management System (BMS) 8S60A (Available on Android/iOS)
    Charge Voltage 28.8±0.4V
    Standard Charge Current 12A
    Fast Charge Current 30A
    Max. Continuous Discharge Current 60A
    Peak Discharge Current 500A (300ms)
    Discharge Cut-off Voltage 20V
    Cycle Life 3000 cycles @ 100% Depth of Discharge (DOD) and 6000 cycles @ 80% DOD
    Self Discharge Rate Less than 3% per month
    Charge Efficiency 100% @0.2C
    Discharge Efficiency 98-100% @1C
    Operating Charge Temperature Range 0°C to 55°C (32°F to 131°F)
    Operating Discharge Temperature Range -20°C to 60°C (-4°F to 140°F)
    Storage Temperature Range -5°C to 45°C (23°F to 113°F)

    Physical Specifications

    • Dimensions: 10.2" x 6.69" x 8.18" in
    • 260×170×208mm (Group 24)
    • Approximate Weight: 26 lbs (12 Kg)
    • Terminal Type: M8
    • Case Color/Material: Black Plastic case (ABS)
    • IP Rating: IP65
    • Cell Type: Cylindrical LiFePO4 cell
    • Cell Holder: Yes

    Additional Information

    • The battery features Bluetooth connectivity, allowing for monitoring via Android and iOS devices.
    • Compliant with international standards including UL 1642, IEC62133, IEC62619, CE, UN38.3, and ROHS.
    • Implemented strict quality control measures ensure reliability and consistency.
    Higher qualified Grade-A cylindrical cells 🔋
    • UL1642, IEC62619, IEC62133 listed with Cycle life more than 3000 times and excellent consistency.
    Bluetooth® Connectivity 📲
    • Monitor the battery status (charge, discharge, current, temperature, cycle life and so on) and change the data for different applications.

    Push Button Wake-Up/Reset Feature 🔄

    • Located Conveniently on top of the battery case, this button allows for easy waking up or resetting of the battery, ensuring quick and effortless operation.

    Built-in Heating ♨️

    • Uniform internal heating is an important feature of our cold-weather performance batteries, as many external heating blanket options currently available cannot sense the internal temperature of the cells and may not be completely effective at heating the battery throughout. Our system features proprietary technology that draws power from the charger itself, requiring no additional components. The entire process of heating and charging is completely seamless. Simply plug the battery into our lithium charger and the internal heating and monitoring system takes care of the rest.
    More stable and firm internal structure ⚙️
    • The cell holders within our battery protect and separate each cell to avoid any short circuit risks caused by intense vibration or impact. The separation and space created between each cell also improves the overall heat dissipation within the battery pack while charging and discharging.
    Abyss Battery® strives to make the safest and most reliable lithium iron phosphate batteries for the most demanding environments, that’s why our batteries are only made with certified components and used in applications around the world. All Abyss Lithium batteries conform to the standard entities and regulations listed below.

    All Abyss Batteries meet and exceed The American Boat & Yacht Council (ABYC) standard for lithium ion batteries. The ABYC council is an organization that develops voluntary global safety standards for the design, construction, maintenance, and repair of recreational boats.

    Abyss Battery Meets ABYC Standards for Lithium Ion Batteries

    We only use cells listed with UL standards entities.
    QUALITY AND ENVIRONMENTAL MANAGEMENT SYSTEMS (ISO Certified)
    ISO 9001:2008 Quality Management System
    ISO 14001:2004 Environmental Management System
    IEC/UL 62133
    IEC62133 certifications and additional laboratory services are available as required by our OEM clients.


    Abyss Battery®, Inc manufacturing process is compliant and licensed on a international level by TÜV Rheinland for Functional Safety as a result of exposure to harsh marine environments such as vibration, impact, ignition protection, water ingress and salt spray corrosion common on pleasure craft and boats. TÜV Rheinland stands for safety and quality in virtually all areas of business and life. TÜV Rheinland’s highly qualified experts test technical systems and products around the world, support innovations in technology and business, train people in numerous professions and certify management systems according to international standards. In doing so, the independent experts generate trust in products as well as processes across global value-adding chains and the flow of commodities. Since 2006, TÜV Rheinland has been a member of the United Nations Global Compact to promote sustainability and combat corruption.

    UN/DOT 38.3: Lithium Battery Transportation

    All Abyss Battery®, Inc. Lithium Batteries are required to pass section 38.3 of the UN Manual of Tests and Criteria, to ensure the safety of using products for our end users and for shipping purposes. We are proud of our investment to ensure our products have been UN38.3 certified.

    T1 – Altitude Simulation
    This is low pressure testing that simulates unpressurized airplane space (cargo area) at 15,000 meter altitude. After storing batteries at 11.6kPa for >6 hours, these criteria shall be met: no mass loss, leaking, venting, disassembly, rupture or fire, and voltage within 10% of pre-test voltage.

    T2 – Thermal Test
    This test covers changes in temperature extremes from -40°C to +75°C.  Batteries are stored for 6 hours at -40°C (12 hours for large cells/batteries), then 6 hours at +75°C (12 hours for large cells/batteries), for a total of 10 cycles. Testing may be performed in a single chamber or thermal shock chamber, but less than 30-minute transitions shall be used.

    T3 – Vibration
    This test simulates vibration during transportation.  Test is a Sine Sweep: 7Hz – 200Hz – 7Hz in 15 Minutes; 12 Sweeps (3 hours); 3 mutually perpendicular axes.

    T4 – Shock
    This test also simulates vibration during transportation.  Test is a Half-Sine pulse: 150G/6ms for small cells/batteries; 50G/11ms for large cells/batteries; 3 pulses per direction; 6 directions (+/-z, +/-x, +/-y).  Same pass criteria as T1.

    T5 – External Short Circuit
    This test simulates an external short to the terminals of the cell or battery. At temperature of +55°C, apply short circuit (<0.1ohm) across terminals.  Maintain at least an hour after sample temperature returns to +55 +/-2°C.  Pass criteria are: Case temperature does not exceed +170°C and no disassembly, rupture, or fire within 6 hours of test.  Fuse, current limiting circuit, and venting mechanism activation are allowable.

    T6 – Impact
    This test is only applicable to primary and secondary cells.  For cylindrical cells >20mm diameter, it simulates impact to case of cell. For cylindrical cells <20mm diameter and all other cell constructions, it simulates crushing of a cell. Pass criteria for any type is: Case temperature does not exceed +170°C & no disassembly or fire within 6 hours of test.

    T7 – Overcharge
    This test is for secondary or rechargeable batteries only.  It simulates an overcharge condition on a rechargeable battery: 2x the manufacturer’s recommended charge current for 24 hours.  Then battery shall be monitored for 7 days for fire or disassembly.

    T8 – Forced Discharge
    This testing simulates a forced discharge condition for primary and secondary cells only.

    Click the links below to view and download owner's manuals and instructions for your Abyss Battery® products.

    ABYSS BATTERY® USER MANUAL

    LITHIUM CHARGER USER MANUAL

    DC-DC CHARGER USER MANUAL

    MULTI_BANK CHARGER USER MANUAL

    REEL BATTERY USER MANUAL

    BLUETOOTH® APP QUICK GUIDE



    Thank you for taking interest in the products we offer at Abyss Battery. This Limited Warranty applies to physical goods, and only physical goods purchased from Abyss Battery. We recommend you protect your investment and register your warranty.

    If your battery is not registered within 90 days of purchase, warranty will begin at manufacture date of battery. Proof of ownership is required. Warranties are not transferrable. Unlike other Lithium battery companies, Abyss Battery has additional support through the purchase of our Extended Warranty program.


    Warranty types: 12V, 24V, 36V, 72V Batteries

    Warranty Coverage Period When expired
    Manufacturer’s Limited Warranty Warranty
Coverage 5-Year Free Replacement After 5 years, 35% Off a New Replacement up to 10-Years
    Extended
 Warranty Extended
Coverage 7-Year Free Replacement After 7 years, 50% off a new Replacement
For Life



    Warranty types: Reel Batteries, Lithium Battery Chargers

    Warranty Coverage Period  When expired
    Manufacturer’s Limited Warranty Warranty
Coverage 2-Year Free Replacement After 2 years, 35% Off a New Replacement up to 5-Years



    One stop for support

    • 24/7 priority access to Battery experts by chat or phone
    • Global repair coverage
    • Onsite repair for Batteries: Request that a technician come to your work site
    • Mail-in repair: Mail in your Battery using a prepaid shipping box provided by Abyss Battery
    • Carry-in repair: Bring your Battery in to our Authorized Service Providers

    How to Buy?

    1. Purchase ReCharge+ for $199.99 with your New Battery (does not apply to reel batteries or chargers.)
    2. Or buy it within 60 days of your Battery purchase:
    • Online: Add extended warranty to your shopping cart when you checkout.
    • By calling: 1+ (855)-719-1727

    What does Limited Warranty cover?

    We guarantee that every battery sold by us or any of our authorized dealers and OEM distributors, to be defect free from the date of purchase. Our Li-ion Batteries are designed to be a drop-in replacement for lead-acid and AGM battery applications. This Limited Warranty covers any defects in materials and workmanship under normal use during the Warranty Period. During the Warranty Period Abyss Battery will repair or replace, at no charge, products or parts of a product that proves defective because of improper workmanship, under normal use and maintenance.


    What will we do to correct  the problems?

    In the unlikely event your battery is defective, we will repair or replace the battery. If the battery is repairable, it will be repaired at no cost and returned to you. If it is not repairable and the issue was caused by a manufacturer defect, we will replace the battery at no cost within the first 5 years. After 5 years, we will repair your battery at no cost to you if the battery is repairable. In the unlikely event it is not repairable, we will prorate the cost of a new replacement battery for you at 35% off the cost of a new one.

    In some cases, your warranty claim may require special order parts and it can take about 2 weeks for us to get the necessary parts and components. If a customer requests a replacement battery right away, the customer will temporarily pay for a replacement and a credit will be issued once the warranted battery is received and found to be defective or in need of repair.


    How long does the Warranty Last?

    • The Warranty period for physical goods purchased from Abyss Battery is 3,650 days (10 years).
    • A replacement battery assumes the remaining warranty of the original battery or 10 years from the date of purchase.

    What does this Limited Warranty not cover?

    This Limited Warranty does not cover any problem that is caused by:

    1. Conditions, malfunctions, or damage not resulting from defects in material or workmanship.
    2. Damages from shipping.
    3. Damages caused by abuse/neglect (DO NOT JUMP START!)
    4. Loose terminal bolts.
    5. Corroded hardware.
    6. Failure to improperly install the battery.
    7. Tampering or removal of manufacturer codes.
    8. Properly charging and maintaining the battery.
    9. Breakage from collision.
    10. Improper storage, which includes damage from water, extreme heat or freezing temperatures.
    11. All bolts must be tightened with a torque wrench and NOT by hand to avoid overheating caused by a loose connection.
    12. Use approved and authorized chargers only.

    What do you have to do?

    • All products purchased must be registered within 90 days of purchase or have an original purchase receipt in order to be eligible for a warranty. If neither of these things are true Abyss Battery reserves the right to deny any warranty claim.
    • All warranty claim batteries must be returned to and received within the warranty period.
    • All shipping of return items and replacement items are the customer’s responsibility unless deemed a manufactured defect.
    • All RMA shipments must be sent with proper Hazardous Goods Paperwork. Shipping your battery back to Abyss Battery without proper paperwork and RMA identification may lead to the loss of your item or the denial of your warranty claim.

    The customer bears the responsibility to properly package the warrantied item so that it will not be damaged during the shipping process. We recommend keeping the original boxing or request a replacement box and use a approved hazmat certified shipping department. Abyss Battery will not bear responsibility for the customer not following the regulated rules and guidelines in returning a battery for a warranty claim. This includes the classification of certifying your warranty claimed item as Dangerous Goods along with the proper packaging, labeling, and using qualified shipper to return the product back to us for assessment.


    Battery Management System

    All of our lithium batteries include a built in battery management system. Our BMS operating system is designed to sense short circuit, reverse polarity, overcharge, and over discharge voltage protection. The BMS prevents failure and will internally disconnect to prevent damage to the cells if it senses any of the following conditions. If your battery has disconnected. Please contact us through the form below and we will guide you through the steps necessary to resolve the issue.


    Back Orders

    Some products may not be readily available and must be ordered from our factory. Within 48 hours after you place your order we will notify you by phone or email if the item is on back order and provide you with the expected ship date. If the products have not yet shipped you can cancel your order anytime. Production delays do happen and we apologize in advance. Abyss Battery will do everything to help you get your products as soon as possible.


    Return Policy

    If you have not used or unboxed your product you are eligible for a refund. Abyss Battery must receive the items you wish to return within 30 days of purchase. If we do not receive your battery with in the time frame a refund will not be issued. Once we receive the items with in the 30 day time frame your refund will be processed. The customer is liable for all shipping expenses and a 20% restocking fee. Abyss Battery values our commitment to excellent customer service and it is our top priority. Please contact us if you have further questions about our warranty and return policy.


    Warranty Disclaimer

    Customers should adhere to all documentation and guidelines. We will not be responsible for any expenses related to installation/removal, electrical system tests, battery charging, loss of time or other expenses which should be considered incidental damages, including all shipping charges after the first 30 days of warranty.

    This warranty applies under conditions of normal use. The warranty does not cover: 1) defects caused by improper assembly or disassembly; 2) defects occurring after purchase due to product modification, intentional damage, accident, misuse, abuse, negligence or exposure to corrosive elements; 3) cosmetic damage and 4) labor or assembly costs. Except as provided herein, Abyss Battery, Inc. makes no express warranties, and any implied warranty, including without limitation any implied warranty of merchantability or fitness for a particular purpose, is limited in its duration to the duration of the written limited warranty set forth herein. Except as provided herein, Abyss Battery, Inc. shall have no liability or responsibility to the purchaser or any other person or entity with respect to any liability, loss or damage caused or alleged to be caused directly or indirectly by use of the product, including, but not limited to, any incidental or consequential damages. Some states do not allow limitation on how long an implied warranty lasts or the exclusion of limitation of incidental or consequential damages, so the above limitation and exclusion may not apply to you. This warranty gives you specific legal rights. You may also have other rights which vary from state to state.


    THE WARRANTY CONTAINED HEREIN IS THE EXCLUSIVE WARRANTY MADE BY ABYSS BATTERY®, INC. AND THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING A WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE OR OF MERCHANTABILITY MADE WITH RESPECT TO SUCH BATTERIES. ABYSS BATTERY, INC. IS NOT LIABLE FOR ANY INJURY OR MISHAPS SUSTAINED IN THE USE OF THIS PRODUCT. THE USER OF THIS PRODUCT ACKNOWLEDGES ASSUMED RISKS AND WAIVES ANY AND ALL CLAIMS AGAINST ABYSS BATTERY, INC. AND ANY OF IT’S AGENTS.

    - Rhodan Marine HD GPS ANCHOR ® Trolling Motor

    - Minn Kota®

    - MotorGuide® XI5 WIRELESS

    - Power-Pole® Trolling Motor

    - Garmin Force® Trolling Motor

    - Lowrance® Ghost Trolling Motor

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    Customer Reviews

    Based on 3 reviews
    100%
    (3)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    L
    Logan Brown
    AWESOME

    They are expensive%2C however it’s definitely worth it. It came 70%25 charged it took just a few minutes to get it hooked up and was charged in less than 3 hours. Fished all day long the next day and barely used 17%25 of the battery. I absolutely love this setup%21%21%21%21%21

    B
    Bryan Banks
    Game changer!!!

    I got the 24 volt 60 AHS unit w/ the onboard charger for my 18’ Silver King. I couldn’t be happier w the upgrade!! I fish hard on my trolling motor regularly and the charge life is outstanding (5-6 trips before needing to plug it in). The reduced weight in the bow also increased top end speed by 4-5 mph. I highly recommend the Abyss lithiums to anybody thinking about going that route w their batteries!

    T
    TIMMOTHY FERLEMAN

    I have not tested it out yet. I will set it up this weekend. i am exited to use it

    MORE EFFICIENT, RELIABLE BATTERY TECHNOLOGY

    Made For 24V Trolling Motors

    We can't imagine how anyone could still be using old-school batteries connected in series.


    Now, anglers get to experience more power and longer run times with our 24V lithium battery solutions. Upgrade today and take your fishing experience up another notch or two.

    Get App

    Search for Abyss Battery® on the Apple App Store or Google Play

    THE BEST CONNECTION FOR BOATERS AND FISHERMEN

    Stay in Control of Your Boat's Power

    Monitor your 24V marine trolling motor battery operation status with New Bluetooth® connectivity.


    Fast, secure connection allows for easy BMS software updates and battery health diagnostic reports via your Apple® or Android™ device.

    FASTER CHARGING TIMES, LONGER RUN TIMES

    Get More Power For Your Boat Without Sacrificing Space

    Abyss batteries deliver 100% useable capacity, consistent power, and superior voltage stability.

    Experience a whole new standard of long lasting performance!

    24V LITHIUM MARINE BATTERIES

    Unmatched Safety and Durability

    All Abyss Batteries are built tough, with a shock-resistant and vibration-resistant construction.


    Our batteries are also fully waterproof and saltwater tested to fully combat corrosion.

    DROP IN INSTALLATION,LITHIUM BATTERY REPLACEMENT

    Proven Reliability and Performance

    Every Abyss Battery® comes equipped with a battery management system (BMS) that ensures your Battery will charge quickly and safely.

    Our technology also offers built in safety features to protect your battery from overcharging, ambient temperature fluctuations, and reverse polarity to maximize cell-life cycles.

    This ONE 24V trolling battery is designed to replace and outperform TWO Group 31 deep-cycle AGM marine batteries in series connection.
