AB-CRG-36V10A

  • In stock, ready to ship
Regular price$499.99
/
Shipping calculated at checkout.
ABYSS® On-Board 36V 10A High-Precision Marine Lithium Battery Charger

Safe
RoHS
Compliant

ABYSS® On-Board 36V 10A High-Precision Marine Lithium Battery Charger

2-year free replacement warranty

ABYSS® On-Board 36V 10A High-Precision Marine Lithium Battery Charger

30 day risk
free money back guarantee

ABYSS® On-Board 36V 10A High-Precision Marine Lithium Battery Charger

Fast & Free Shipping

Elevate your charging experience with our On-Board 36V 10A High Precision Lithium Charger, meticulously engineered to deliver unparalleled efficiency, intelligence, and speed in battery charging. Designed specifically for the Abyss Battery® 36V 60Ah Lithium Trolling Motor Battery, this charger is your key to unlocking longer run times and dramatically shorter charge times, ensuring you spend more time on the water and less time waiting for a charge.

Invest in the On-Board 36V 10A High Precision Lithium Charger for the Abyss Battery® 36V 60Ah Lithium Trolling Motor Battery and transform your charging process. Our charger not only promises exceptional performance and reliability but also provides the peace of mind that comes with advanced safety features. Optimize your time on the water with a charger that stands at the forefront of technology, offering you the quickest, most intelligent, and efficient charging solution.

Features:

  • IP68 Rating.
  • 2-Year Warranty.
  • Marine-grade construction.
  • Overcurrent limit.
  • High voltage safety.
  • Reverse connection protection.
  • Temperature protection.
  • Full-Auto timing shutdown.
  • Anti-Walking function.
  • LED indicator for Charging Process.
  • CAN communication (optional).
  • 12V5A Auxiliary power supply (optional).

Safety:

  • Short-Circuit: Yes
  • Open-Circuit: Yes
  • Overheating: Yes
  • Overcharge: Yes
  • Spark-Proof: Yes
  • Reverse Polarity: Yes

Size:

  • Height: 6.5 Inches (165.1mm)
  • Width: 7.9 Inches (201.3mm)
  • Depth: 2.2 Inches (56.0mm)
  • Weight: 6.1 Pounds (2.7kg)

Operating Requirements:

  • Line Voltage: 120V to 240V AC
  • Frequency: 50Hz to 60Hz
  • Operating Temperature: -4° to 104° F (-20° to 50° C)
  • Storage Temperature: -22° to 140° F (-30° to 60° C)
  • Relative Humidity: 0 to 95% Non-Condensing

Cord Management:

  • DC Cable + Eyelet Length: 72 Inches (182cm)
  • DC Cable Size: 16 AWG
  • DC Fuse Size: 7.5 AMP MINI ® Blade Fuse
  • AC Cable Length: 72 Inches (182cm)
  • AC Cable Size: 18 AWG
  • Oil, gas, grease, water, chemical, UV, abrasion resistant
  • Red = Negative, Yellow/Green = Ground, Purple = Neutral

Marine Lithium Battery Charger Datasheet

Product name

24V10A

24V20A

36V10A

36V20A

Model

AB-CRG-24V10A

AB-CRG-24V20A

AB-CRG-36V10A

AB-CRG-36V20A

Amps

10A

20A 10A 20A

Physical Dimensions



7.5” x 5” x 2.5”
(190 x 127 x 63 mm)

7.5” x 5” x 2.5”
(190 x 127 x 63 mm)

7.5” x 5” x 3”

(190 x 127 x 76 mm)

10.5” x 6” x 3”
(267 x 152 x 76 mm)

Nominal AC input voltage



100-240V AC

100-240V AC 120-240V AC 120-240V AC

Nominal AC input frequency



50/60Hz

50/60Hz 50/60Hz 50/60Hz

Charging Battery Type



24V Lithium Trolling Motor Battery

24V Lithium Trolling Motor Battery 36V Lithium Trolling Motor Battery 36V Lithium Trolling Motor Battery

Weight

3.3 lbs (1.5 kg) 3.3 lbs (1.5 kg) 3.6 lbs (1.6 kg) 7.1 lbs (3.2 kg)

Working Temp Range

-20°C~50°C

-20°C~50°C -20°C~50°C -20°C~50°C

    Abyss Battery® strives to make the safest and most reliable lithium iron phosphate batteries for the most demanding environments, that’s why our batteries are only made with certified components and used in applications around the world. All Abyss Lithium batteries conform to the standard entities and regulations listed below.

    All Abyss Batteries meet and exceed The American Boat & Yacht Council (ABYC) standard for lithium ion batteries. The ABYC council is an organization that develops voluntary global safety standards for the design, construction, maintenance, and repair of recreational boats.

    Abyss Battery Meets ABYC Standards for Lithium Ion Batteries

    We only use cells listed with UL standards entities.
    QUALITY AND ENVIRONMENTAL MANAGEMENT SYSTEMS (ISO Certified)
    ISO 9001:2008 Quality Management System
    ISO 14001:2004 Environmental Management System
    IEC/UL 62133
    IEC62133 certifications and additional laboratory services are available as required by our OEM clients.


    Abyss Battery®, Inc manufacturing process is compliant and licensed on a international level by TÜV Rheinland for Functional Safety as a result of exposure to harsh marine environments such as vibration, impact, ignition protection, water ingress and salt spray corrosion common on pleasure craft and boats. TÜV Rheinland stands for safety and quality in virtually all areas of business and life. TÜV Rheinland’s highly qualified experts test technical systems and products around the world, support innovations in technology and business, train people in numerous professions and certify management systems according to international standards. In doing so, the independent experts generate trust in products as well as processes across global value-adding chains and the flow of commodities. Since 2006, TÜV Rheinland has been a member of the United Nations Global Compact to promote sustainability and combat corruption.

    UN/DOT 38.3: Lithium Battery Transportation

    All Abyss Battery®, Inc. Lithium Batteries are required to pass section 38.3 of the UN Manual of Tests and Criteria, to ensure the safety of using products for our end users and for shipping purposes. We are proud of our investment to ensure our products have been UN38.3 certified.

    T1 – Altitude Simulation
    This is low pressure testing that simulates unpressurized airplane space (cargo area) at 15,000 meter altitude. After storing batteries at 11.6kPa for >6 hours, these criteria shall be met: no mass loss, leaking, venting, disassembly, rupture or fire, and voltage within 10% of pre-test voltage.

    T2 – Thermal Test
    This test covers changes in temperature extremes from -40°C to +75°C.  Batteries are stored for 6 hours at -40°C (12 hours for large cells/batteries), then 6 hours at +75°C (12 hours for large cells/batteries), for a total of 10 cycles. Testing may be performed in a single chamber or thermal shock chamber, but less than 30-minute transitions shall be used.

    T3 – Vibration
    This test simulates vibration during transportation.  Test is a Sine Sweep: 7Hz – 200Hz – 7Hz in 15 Minutes; 12 Sweeps (3 hours); 3 mutually perpendicular axes.

    T4 – Shock
    This test also simulates vibration during transportation.  Test is a Half-Sine pulse: 150G/6ms for small cells/batteries; 50G/11ms for large cells/batteries; 3 pulses per direction; 6 directions (+/-z, +/-x, +/-y).  Same pass criteria as T1.

    T5 – External Short Circuit
    This test simulates an external short to the terminals of the cell or battery. At temperature of +55°C, apply short circuit (<0.1ohm) across terminals.  Maintain at least an hour after sample temperature returns to +55 +/-2°C.  Pass criteria are: Case temperature does not exceed +170°C and no disassembly, rupture, or fire within 6 hours of test.  Fuse, current limiting circuit, and venting mechanism activation are allowable.

    T6 – Impact
    This test is only applicable to primary and secondary cells.  For cylindrical cells >20mm diameter, it simulates impact to case of cell. For cylindrical cells <20mm diameter and all other cell constructions, it simulates crushing of a cell. Pass criteria for any type is: Case temperature does not exceed +170°C & no disassembly or fire within 6 hours of test.

    T7 – Overcharge
    This test is for secondary or rechargeable batteries only.  It simulates an overcharge condition on a rechargeable battery: 2x the manufacturer’s recommended charge current for 24 hours.  Then battery shall be monitored for 7 days for fire or disassembly.

    T8 – Forced Discharge
    This testing simulates a forced discharge condition for primary and secondary cells only.

    Click the links below to view and download owner's manuals and instructions for your Abyss Battery® products.

    ABYSS BATTERY® USER MANUAL

    LITHIUM CHARGER USER MANUAL

    DC-DC CHARGER USER MANUAL

    MULTI_BANK CHARGER USER MANUAL

    REEL BATTERY USER MANUAL

    BLUETOOTH® APP QUICK GUIDE



    Thank you for taking interest in the products we offer at Abyss Battery. This Limited Warranty applies to physical goods, and only physical goods purchased from Abyss Battery. We recommend you protect your investment and register your warranty.

    If your battery is not registered within 90 days of purchase, warranty will begin at manufacture date of battery. Proof of ownership is required. Warranties are not transferrable. Unlike other Lithium battery companies, Abyss Battery has additional support through the purchase of our Extended Warranty program.


    Warranty types:

    Warranty Coverage Period When expired
    Manufacturer’s Limited Warranty Warranty
Coverage 5-Year Free Replacement After 5 years, 35% Off a New Replacement up to 10-Years
    Extended
Warranty Extended
Coverage 7-Year Free Replacement After 7 years, 50% off a new Replacement
For Life

    Electric Fishing Reel Batteries and Marine Lithium Battery Chargers both have a 2-Year Free Replacement Warranty.

    Enjoy 7 years of peace of mind when you buy ReCharge+ for your Battery. ReCharge+ for Abyss Battery® Extends your Free 5-Year Replacement Coverage by 2+ additional years from your purchase. In addition to a free battery replacement, you’ll get 24/7 priority access to our Battery experts by chat or phone.(only applies to marine batteries, does not include reel batteries or marine chargers)


    One stop for support

    • 24/7 priority access to Battery experts by chat or phone
    • Global repair coverage
    • Onsite repair for Batteries: Request that a technician come to your work site
    • Mail-in repair: Mail in your Battery using a prepaid shipping box provided by Abyss Battery
    • Carry-in repair: Bring your Battery in to our Authorized Service Providers

    How to Buy?

    1. Purchase ReCharge+ for $199.99 with your New Battery.
    2. Or buy it within 60 days of your Battery purchase:
    • Online: Add extended warranty to your shopping cart when you checkout.
    • By calling: 1+ (855)-719-1727

    What does Limited Warranty cover?

    We guarantee that every battery sold by us or any of our authorized dealers and OEM distributors, to be defect free from the date of purchase. Our Li-ion Batteries are designed to be a drop-in replacement for lead-acid and AGM battery applications. This Limited Warranty covers any defects in materials and workmanship under normal use during the Warranty Period. During the Warranty Period Abyss Battery will repair or replace, at no charge, products or parts of a product that proves defective because of improper workmanship, under normal use and maintenance.


    What will we do to correct  the problems?

    In the unlikely event your battery is defective, we will repair or replace the battery. If the battery is repairable, it will be repaired at no cost and returned to you. If it is not repairable and the issue was caused by a manufacturer defect, we will replace the battery at no cost within the first 5 years. After 5 years, we will repair your battery at no cost to you if the battery is repairable. In the unlikely event it is not repairable, we will prorate the cost of a new replacement battery for you at 35% off the cost of a new one.

    In some cases, your warranty claim may require special order parts and it can take about 2 weeks for us to get the necessary parts and components. If a customer requests a replacement battery right away, the customer will temporarily pay for a replacement and a credit will be issued once the warranted battery is received and found to be defective or in need of repair.


    How long does the Warranty Last?

    • The Warranty period for physical goods purchased from Abyss Battery is 3,650 days (10 years).
    • A replacement battery assumes the remaining warranty of the original battery or 10 years from the date of purchase.

    What does this Limited Warranty not cover?

    This Limited Warranty does not cover any problem that is caused by:

    1. Conditions, malfunctions, or damage not resulting from defects in material or workmanship.
    2. Damages from shipping.
    3. Damages caused by abuse/neglect (DO NOT JUMP START!)
    4. Loose terminal bolts.
    5. Corroded hardware.
    6. Failure to improperly install the battery.
    7. Tampering or removal of manufacturer codes.
    8. Properly charging and maintaining the battery.
    9. Breakage from collision.
    10. Improper storage, which includes damage from water, extreme heat or freezing temperatures.
    11. All bolts must be tightened with a torque wrench and NOT by hand to avoid overheating caused by a loose connection.
    12. Use approved and authorized chargers only.

    What do you have to do?

    • All products purchased must be registered within 90 days of purchase or have an original purchase receipt in order to be eligible for a warranty. If neither of these things are true Abyss Battery reserves the right to deny any warranty claim.
    • All warranty claim batteries must be returned to and received within the warranty period.
    • All shipping of return items and replacement items are the customer’s responsibility unless deemed a manufactured defect.
    • All RMA shipments must be sent with proper Hazardous Goods Paperwork. Shipping your battery back to Abyss Battery without proper paperwork and RMA identification may lead to the loss of your item or the denial of your warranty claim.

    The customer bears the responsibility to properly package the warrantied item so that it will not be damaged during the shipping process. We recommend keeping the original boxing or request a replacement box and use a approved hazmat certified shipping department. Abyss Battery will not bear responsibility for the customer not following the regulated rules and guidelines in returning a battery for a warranty claim. This includes the classification of certifying your warranty claimed item as Dangerous Goods along with the proper packaging, labeling, and using qualified shipper to return the product back to us for assessment.


    Battery Management System

    All of our lithium batteries include a built in battery management system. Our BMS operating system is designed to sense short circuit, reverse polarity, overcharge, and over discharge voltage protection. The BMS prevents failure and will internally disconnect to prevent damage to the cells if it senses any of the following conditions. If your battery has disconnected. Please contact us through the form below and we will guide you through the steps necessary to resolve the issue.


    Back Orders

    Some products may not be readily available and must be ordered from our factory. Within 48 hours after you place your order we will notify you by phone or email if the item is on back order and provide you with the expected ship date. If the products have not yet shipped you can cancel your order anytime. Production delays do happen and we apologize in advance. Abyss Battery will do everything to help you get your products as soon as possible.


    Return Policy

    If you have not used or unboxed your product you are eligible for a refund. Abyss Battery must receive the items you wish to return within 30 days of purchase. If we do not receive your battery with in the time frame a refund will not be issued. Once we receive the items with in the 30 day time frame your refund will be processed. The customer is liable for all shipping expenses and a 20% restocking fee. Abyss Battery values our commitment to excellent customer service and it is our top priority. Please contact us if you have further questions about our warranty and return policy.


    Warranty Disclaimer

    Customers should adhere to all documentation and guidelines. We will not be responsible for any expenses related to installation/removal, electrical system tests, battery charging, loss of time or other expenses which should be considered incidental damages, including all shipping charges after the first 30 days of warranty.

    This warranty applies under conditions of normal use. The warranty does not cover: 1) defects caused by improper assembly or disassembly; 2) defects occurring after purchase due to product modification, intentional damage, accident, misuse, abuse, negligence or exposure to corrosive elements; 3) cosmetic damage and 4) labor or assembly costs. Except as provided herein, Abyss Battery, Inc. makes no express warranties, and any implied warranty, including without limitation any implied warranty of merchantability or fitness for a particular purpose, is limited in its duration to the duration of the written limited warranty set forth herein. Except as provided herein, Abyss Battery, Inc. shall have no liability or responsibility to the purchaser or any other person or entity with respect to any liability, loss or damage caused or alleged to be caused directly or indirectly by use of the product, including, but not limited to, any incidental or consequential damages. Some states do not allow limitation on how long an implied warranty lasts or the exclusion of limitation of incidental or consequential damages, so the above limitation and exclusion may not apply to you. This warranty gives you specific legal rights. You may also have other rights which vary from state to state.


    THE WARRANTY CONTAINED HEREIN IS THE EXCLUSIVE WARRANTY MADE BY ABYSS BATTERY®, INC. AND THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING A WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE OR OF MERCHANTABILITY MADE WITH RESPECT TO SUCH BATTERIES. ABYSS BATTERY, INC. IS NOT LIABLE FOR ANY INJURY OR MISHAPS SUSTAINED IN THE USE OF THIS PRODUCT. THE USER OF THIS PRODUCT ACKNOWLEDGES ASSUMED RISKS AND WAIVES ANY AND ALL CLAIMS AGAINST ABYSS BATTERY, INC. AND ANY OF IT’S AGENTS.

    This site is protected by reCAPTCHA and the Google Privacy Policy and Terms of Service apply.

    Customer Reviews

    Based on 26 reviews
    92%
    (24)
    8%
    (2)
    0%
    (0)
    0%
    (0)
    0%
    (0)
    L
    Lee Landrum
    Great Service

    Prior charger died. I called and explained what the charger was doing and what voltage the battery was showing. The tech at Abyss figured most likely cause was bad charger and sent me a new one. I had the new one 2 days later.

    B
    Bobby Barbuto
    Battery Charger

    I would like to thank Nic and the people that this company for the quality that they give you when you purchase stuff from them. The battery charger is easy to install and works great thank you 47 Freeman.

    J
    John Turner
    Abyss warranty

    I replaced another brand of lithium battery after have 3 failures with that brand in a year along with it right at three months to get the last one replaced, I gave up trying to get a replacement, and after talking to Abyss battery’s (Ryan) I purchased their battery I can say everything Ryan stated that made me choose them came to the test recently after running their battery 1 1/2 years I had an issue it was determined my charger quite working. They if this does not fix the issue they would get a new battery shipped to me. Charger was sent same day I received the new one connected it up and all was well. It’s nice to work with a company that listens to their customers and stands behind the product the way they do, no hassles. I highly recommend abyss to anyone looking at lithium technology ps abyss batter is much smaller than the previous battery and has served me well. Thanks Abyss

    R
    Russel Broussard
    Amazing

    At first I was skeptical about this charger. But after using it every weekend I can say how impressed I am with it. It was super easy to install. I did it myself. I fish offshore only. I have long runs between spots sometimes up to an hour. And since I have installed this charger my battery has never gone below 90 percent !!! I wish I would have got it sooner. I also have the 36v lithium battery. This combo woke up my trolling motor. It’s like I bought a new trolling motor. Great product.

    M
    Mark Nichols
    AC battery charger

    Plug and play install. It just works. What more can you say?

    ON-BOARD LITHIUM BATTERY CHARGERS

    Made For Your Abyss Battery

    Our Marine Chargers deliver 99% Charge effeciency, consistent power, and superior voltage stability. The features that provide an accurate charge and protect your battery for the long haul, so it'll run like new for years to come.

    Get App

    Search for Abyss Battery® on the Apple App Store or Google Play

    How to Select the Perfect Lithium Battery Charger for Your Needs

    When it comes to powering your marine adventures, choosing the right lithium battery charger is crucial.

    At Abyss Battery, we understand the importance of reliability and durability in the harsh marine environment. That's why our chargers are engineered to withstand the toughest conditions.

    Our chargers boast a robust, shock-resistant, and vibration-resistant construction, ensuring they remain operational even in the most challenging situations.

    Additionally, they are fully waterproof with an IP68 rating, providing complete protection against water ingress. We've also rigorously saltwater tested our chargers to guarantee they can resist corrosion, a common issue in marine settings.

    Investing in an Abyss Battery charger means choosing peace of mind, knowing your marine lithium batteries will be charged efficiently and safely, no matter where your journey takes you.

    Experience Unparalleled Durability with Rugged Construction

    Unlock Smart and Efficient Charging

    Embark on your marine adventures with confidence, thanks to our IP68 waterproof design. Abyss batteries are crafted to withstand the harshest marine environments, ensuring your power source remains safe and reliable, no matter the conditions.

    Experience the ultimate convenience with our advanced charging technology. Get the quickest, most intelligent, and efficient charge for your lithium battery. Our innovative LED lights provide real-time monitoring of connection, power status, and state of charge, keeping you informed and in control.
