12V 350Ah Battery Specifications
12V 350Ah Battery Datasheet
| Technical Specifications | Details |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 350Ah |
| Parallel Connection | Maximum 6 units |
| Serial Connection | Maximum 4 units |
| Bluetooth Management System (BMS) | 4S200A (Available on Android/iOS) |
| Charge Voltage | 14.4±0.2V |
| Standard Charge Current | 70A |
| Fast Charge Current | 175A |
| Max. Continuous Discharge Current | 200A |
| Peak Discharge Current | 800A (300ms) |
| Discharge Cut-off Voltage | 10V |
| Cycle Life | 3000 cycles @ 100% Depth of Discharge (DOD) and 6000 cycles @ 80% DOD |
| Self Discharge Rate | Less than 3% per month |
| Operating Charge Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Operating Discharge Temperature Range | -20°C to 60°C (-4°F to 140°F) |
| Storage Temperature Range | -5°C to 45°C (23°F to 113°F) |
Physical Specifications
- Dimensions: 20.47" x 10.59" x 8.66" in
- 521×267×220mm (Group 8D)
- Approximate Weight: 75 lbs (34 Kg)
- Terminal Type: M8
- Case Color/Material: Black Plastic case (ABS)
- IP Rating: IP65
- Cell Type: Cylindrical LiFePO4 cell
- Cell Holder: Yes
Additional Information
- The battery features Bluetooth connectivity, allowing for monitoring via Android and iOS devices.
- Compliant with international standards including UL 1642, IEC62133, IEC62619, CE, UN38.3, and ROHS.
- Implemented strict quality control measures ensure reliability and consistency.
