36V 72Ah Battery Datasheet

36V 72Ah Battery Datasheet

Technical Specifications Details
Nominal Voltage 38.4V
Nominal Capacity 72Ah
Parallel Connection Maximum 4 units
Series Connection No
Bluetooth Management System (BMS) 12S80A (Available on Android/iOS)
Charge Voltage 43.2±0.6
Standard Charge Current 15A
Fast Charge Current 36A
Max. Continuous Discharge Current 72A
Peak Discharge Current 600A (300ms)
Discharge Cut-off Voltage 30V
Cycle Life 3000 cycles @ 100% Depth of Discharge (DOD) and 6000 cycles @ 80% DOD
Self Discharge Rate Less than 3% per month
Charge Efficiency 100% @0.2C
Discharge Efficiency 98-100% @1C
Operating Charge Temperature Range 0°C to 55°C (32°F to 131°F)
Operating Discharge Temperature Range -20°C to 60°C (-4°F to 140°F)
Storage Temperature Range -5°C to 45°C (23°F to 113°F)

Physical Specifications

  • Dimensions: 19.0" x 6.69" x 9.44" in
  • 490×171×240mm (Group 49)
  • Approximate Weight:  48.5 lbs (22 Kg)
  • Terminal Type: M8
  • Case Color/Material: Black Plastic case (ABS)
  • IP Rating: IP65
  • Cell Type: Cylindrical LiFePO4 cell
  • Cell Holder: Yes

Additional Information

  • The battery features Bluetooth connectivity, allowing for monitoring via Android and iOS devices.
  • Compliant with international standards including UL 1642, IEC62133, IEC62619, CE, UN38.3, and ROHS.
  • Implemented strict quality control measures ensure reliability and consistency.
