ABYSS® On-Board 36V 10A High-Precision Marine Lithium Battery Charger
AB-CRG-36V10A
- In stock, ready to ship
ABYC Compliant
2-year free replacement warranty
IP67 Water Rating
Ignition Protection
Elevate your charging experience with our On-Board 36V 10A High Precision Lithium Charger, meticulously engineered to deliver unparalleled efficiency, intelligence, and speed in battery charging. Designed specifically for the ABYSS® 36V 60Ah and 36V 72Ah Lithium Trolling Motor Batteries, this charger is your key to unlocking longer run times and dramatically shorter charge times, ensuring you spend more time on the water and less time waiting for a charge.
Our charger not only promises exceptional performance and reliability but also provides the peace of mind that comes with advanced safety features. Additionally this marine battery charger offers wide range compatibility and be used for other brands of 36-Volt Lithium Batteries. Optimize your time on the water with a charger that stands at the forefront of technology, offering you the quickest, most intelligent, and efficient charging solution.
Features:
- IP68 Rating.
- 2-Year Warranty.
- Marine-grade construction.
- Ignition Protection.
- Overcurrent limit.
- High voltage safety.
- Reverse connection protection.
- Temperature protection.
- Full-Auto timing shutdown.
- Anti-Walking function.
- LED indicator for Charging Process.
- CAN communication (optional).
- 12V5A Auxiliary power supply (optional).
Safety:
- Short-Circuit: Yes
- Open-Circuit: Yes
- Overheating: Yes
- Overcharge: Yes
- Spark-Proof: Yes
- Reverse Polarity: Yes
Size:
- Length: 7.5 Inches (190mm)
- Width: 5 Inches (127mm)
- Height: 2.5 Inches (63mm)
- Weight: 3.3 Pounds (1.5kg)
Operating Requirements:
- Line Voltage: 120V to 240V AC
- Frequency: 50Hz to 60Hz
- Operating Temperature: -4° to 104° F (-20° to 50° C)
- Storage Temperature: -22° to 140° F (-30° to 60° C)
- Relative Humidity: 0 to 95% Non-Condensing
Cord Management:
- DC Cable + Eyelet Length: 4' (48 In.) (122 cm)
- DC Cable Size: 16 AWG
- DC Fuse Size: 7.5 AMP MINI ® Blade Fuse
- AC Cable Length: 4' (48 In.) (122 cm)
- AC Cable Size: 18 AWG
- Oil, gas, grease, water, chemical, UV, abrasion resistant
- Red = Negative, Yellow/Green = Ground, Purple = Neutral
ON-BOARD Battery Chargers
|
Product name |
3-Bank 12v/24v marine charger |
3-BANK 12v/36v MARINE CHARGER |
4-BANK 12V MARINE CHARGER |
4-BANK 12V/36V MARINE CHARGER |
36V Alternator CHARGER | 30V-90V Input to 12v 50A DC Step down converter | 36V 10A HIGH- PRECISION CHARGER | 36V 20A HIGH- PRECISION CHARGER | 24V 10A HIGH- PRECISION CHARGER | 24V 20A HIGH- PRECISION CHARGER | 24V ALTERNATOR CHARGER |
|
Model |
AB-CRG-12V24V-3B |
AB-CRG-12V36V-3B |
AB-CRG-12V-4B |
AB-CRG-12V/36V-4B |
AB-36V-DC | AB-DC-SD | AB-CRG-36V10A | AB-CRG-36V20A | AB-CRG-24V10A | AB-CRG-24V20A | AB-24V-DC |
|
Voltage |
12V/24V |
12V/36V | 12V | 12V/36V | 36V | 30V-90V | 36V | 36V | 24V | 24V | 24V |
|
Output |
2x12V/10A +24V/10A |
2x12V/10A +36V/10A | 4x12V/10A |
3x12V/10A +36V/10A |
43.8V/10A | 12V/50A DC | 36V/10A DC | 36V/20A | 24V/10A | 24V/20A | 24V |
|
Product Size
|
11.9" x 9.6" x 3.8" |
14.2" x 9.6" x 3.8" 361 x 245 x 99mm |
11.9" x 9.6" x 3.8" 304 x 245 x 99mm |
16.6" x 9.6" x 3.8" 423 x 245 x 99mm |
6" x 5" x 2" 150 x 130 x 48mm |
6" x 5" x 2" 150 x 130 x 48mm |
7.5" x 5" x 2.75" 190 x 127 x 70mm |
10.5" x 6" x 3" 267 x 152 x 76mm |
7.5" x 5" x 2.5" 190 x 127 x 63mm |
7.75" x 5" x 3" 197 x 127 x 76mm |
4.75" x 3.25" x 1.25" 121 x 82 x 32mm |
| Weight | 16.5 lbs (7.5 kg) |
19 lbs (8.6 kg) | 17 lbs (7.7 kg) | 26.8 lbs (12.1 kg) | 3.1 lbs (1.4 kg) | 3.1 lbs (1.4 kg) | 3.5 lbs (1.6 kg) | 7.1 lbs (3.2 kg) | 3.3 lbs (1.5 kg) | 3.3 lbs (1.5 kg) | .95 lbs (.43 kg) |
| Lead Length | 6' (72 in.) (183 cm) |
6' (72 in.) (183 cm) |
6' (72 in.)(183 cm) | 6' (72 in.) (183 cm) |
7 in. (17.8 cm) |
N/A | 4' (48 in.)(122 cm) |
4' (48 in.)(122 cm) | 3' (36 in.) (91.4 cm) |
3' (36 in.) (91.4 cm) | 7 in. (17.8 cm) |
|
Charging Battery Type
|
Two banks have MODE buttons to choose charging battery type: 12V LiFePO4, 12V Wet, 12V AGM; The 3rd bank could charge 24V LiFePO4 Lithium Batteries |
Two banks have MODE buttons to choose charging battery type: 12V LiFePO4, 12V Wet, 12V AGM; The 3rd bank could charge 36V LiFePO4 Lithium Batteries |
Each bank has one MODE button to choose charging battery type: 12V LiFePO4, 12V Wet, 12V AGM |
Three banks have MODE buttons to choose charging battery type: 12V LiFePO4, 12V Wet, 12V AGM; The 4th bank could charge 36V LiFePO4 Lithium Batteries | 36V LiFePO4 Batteries | 12V LiFePO4 Batteries | 36V LiFePO4 Batteries | 36V LiFePO4 Batteries | 24V LiFePO4 Batteries | 24V LiFePO4 Batteries | 24V LiFePO4 Batteries |
| FOR ALL CHARGERS (if applicable) |
|
|
LED Indicators |
Power & Battery Type & Charging Status LED Indicators |
|
Activate Function |
Wake Up Function for Low Voltage of Lithium Battery (Press the mode button on the bank panel for 3-5 seconds to start this function) |
|
Full Cut-off Voltage |
14.1V-14.4V for 12V Lead Acid Battery & 14.4V-14.7V for 12V AGM / LiFePO4 Lithium Battery & 28.8V-29.4V for 24V Lithium Battery & 43.3V-44.2V for 36V Lithium Battery |
|
Cooling Type |
Aluminium stretched plate and waterproof cooling fan at the bottom of product for better heat dissipation |
|
Ingress Protection |
Filled with pure epoxy resin for high waterproof level IP67
|
|
Circuit Protection |
Short-circuit Protection & Reverse Connection Protection & Overcharge Protection & Overtemp Protection
|
|
Working Temperature Range |
-10°C~40°C |
|
Nominal Working Temperature |
25°C |
|
Relative Humidity |
5%~95% |
